Horizontal Hydraulic Scrap Baler Machine
Overview
General-purpose horizontal scrap baler sized for aluminium cans, light ferrous scrap and mixed metal streams at yard scale.
The Horizontal Hydraulic Scrap Baler Machine is our general-purpose metal scrap platform, sized and tuned for aluminium cans, light ferrous scrap and mixed metal streams rather than the heavier structural sections a dedicated shear or heavy-duty baler is built for.
It's a common fit for can recyclers, scrap dealers and yards that need reliable, repeatable baling on everyday metal scrap volumes.
Machine images
Front View
Side View
Rear View
Available models & capacities
| Model | Capacity |
|---|---|
| NSG HSB-80 | 80 Ton pressing force |
| NSG HSB-130 | 130 Ton pressing force |
| NSG HSB-200 | 200 Ton pressing force |
Technical specifications
| Pressing Force | 80 - 200 Ton |
|---|---|
| Bale Size | 350 x 350 x 350mm to 550 x 450 x 450mm |
| Feed Opening Size | 1400 x 900mm to 1900 x 1200mm |
| Cylinder Size | 1-2 cylinders, Ø170mm - Ø290mm bore |
| Motor Power | 18 HP - 55 HP |
| Hydraulic Pressure | 220 - 280 kg/cm² |
| Pump Capacity | 60 - 150 LPM |
| Oil Tank Capacity | 320 - 700 Litres |
| Cycle Time | 45 - 80 seconds per bale |
| Machine Weight | 5 - 13 Tons |
| Overall Dimensions | 4m x 2m x 2.5m (approx., model dependent) |
| Power Supply | 415V, 3 Phase, 50Hz |
| Control Panel | PLC / push-button control panel |
| Automation Type | Semi-automatic / fully automatic with conveyor feed |
Features
Applications
- Aluminium & UBC can baling
- Light ferrous scrap baling
- Mixed metal scrap consolidation
- General scrap yard baling
Industries served
- Can recycling centres
- Scrap trading yards
- Non-ferrous recyclers
- Waste management companies
Standard accessories
- Hydraulic power pack
- PLC / push-button control panel
- Safety guarding
- Bale ejection ramp
- Manual strapping guides
Optional accessories
- Motorised conveyor infeed
- Automatic strapping station
- Bale weighing system
- PLC-HMI upgrade
Media & documentation
Working video
Available on request
Technical drawing
Available on request
Machine brochure (PDF)
Available on request
Warranty
12 months on machine and hydraulic system; 6 months on electricals.
Installation & commissioning
Foundation guidance, on-site installation, hydraulic commissioning and operator training included.
Delivery time
5 - 7 weeks from order confirmation.
Spare parts availability
Cylinders, seals, pumps, valves and control components stocked for quick dispatch.
After-sales service & AMC
AMC plans, preventive maintenance visits and breakdown support.
Customisation options
- Custom bale size for specific logistics needs
- Higher tonnage cylinder for denser bales
- Conveyor-fed automatic loading
Frequently asked questions
Answers to what buyers most often ask before ordering this machine.
Yes, this general-purpose platform is commonly configured for aluminium and UBC can baling as well as light ferrous and mixed metal scrap.
